Single Head Screw Locking Machine
The single-head screw locking machine is an efficient and precise automated equipment that can automatically complete the rapid locking operation of a single screw, greatly improving production efficiency and quality.
Instructions for use of air-blowing automatic screw locking machine:
1. Mainly composed of automatic screw conveying system, X-Y-Z mobile platform, control system and locking system
2. Strong applicability. To replace products, you only need to replace the fixture. The equipment program is saved separately and the corresponding program can be called out
3. The feeding is controlled by sensors. After locking one by one, it is automatically fed without repeated feeding
4. Slipping teeth do not feed: In the locking process, the torque is not reached and the screw is not sent out to prevent the nozzle from getting stuck
5. Good stability, no material jamming. Even if the material jamming is caused by defects, non-professionals can solve the jamming within a few seconds
6. High efficiency, generally one screw is driven in 1 second. You don’t need to grab the screw. You just need to put the product on the fixture to operate the equipment
7. It can reduce the screw locking operation of 3 workers, realize fully automated production, reduce the labor intensity of workers, and improve productivity
8. The key parts are made of high-quality hardware materials and are specially treated. The original electronic components are imported to ensure zero equipment failure.
